TPMS for earthmoving
TPMS developed for earthmoving
OTR TPMS for Earthmoving Equipment
For OTR and earthmoving machines that endure a lot and are almost constantly in use, tire pressure has a significant impact on operational costs and reliability. Impaqed Products offers a TPMS solution specifically developed for OTR use, tailored to the specific usage and conditions.
Some of our products often used in TPMS for earthmoving
Alle producten
About TPMS for Earthmoving
Specifically for earthmoving: monitoring under high pressure. In earthmoving, large machines often operate day and night, which is a heavy burden. Tire pressure is also a critical issue in this field; one day operating with a tire pressure that is to low, damages the carcass of the tire. For monitoring tire pressure in earthmoving, we have developed special sensors that fit OTR valves and are resistant to harsh conditions.
Our system is also available for harbour cranes, providing you with the perfect solution to equip your vehicles with our TPMS.
Product Features of OTR TPMS
The OTR TPMS provides real-time monitoring of tire pressure and temperature, enhancing reliability and availability while extending the lifespan of your tires. The system is easy to install, and the LCD monitor displays tire pressure and temperature. There is an automatic warning if the tire pressure is abnormally high or low compared to the set thresholds.
Technical Specifications
OTR Sensor:
- Frequency: 434.1 MHz
- Transmission power: 0dBm
- Pressure range: 0 – 13 bar
- Accuracy: approx. 0.15 bar
- Range: approx. 10 meters
- Operating temperature: -40 °C ~ +125 °C
- Battery life: approx. 4 ~ 5 years
- Dimensions: 30 x 35 mm
Alarm Functions
- Low Pressure Level 1 Alarm: triggered when the tire pressure is 12.5% lower than the set standard value.
- Low Pressure Level 2 Alarm: triggered when the tire pressure is 25% lower than the set standard value.
- Low Pressure Level 3 Alarm: triggered when the tire pressure is 50% lower than the set standard value.
- High Pressure Alarm: triggered when the tire pressure is 25% higher than the set standard value.
- Fast Leak Alarm: triggered when the tire pressure drops by more than 3 psi within 12 seconds.
- Transmitter Trouble Alarm: triggered when a wheel sensor fails or when RF interference disrupts the signal.
- High Temperature Alarm: triggered when the measured temperature exceeds 90°C.
This comprehensive and robust TPMS solution from Impaqed Products ensures that your OTR and earthmoving machines always perform optimally, providing you with longer tire life and greater reliability.
4o
About TPMS for Earthmoving
Large earthmoving machines often operate 24/7 under heavy loads, making tire pressure crucial to avoid costly blowouts and delays. We offer special sensors for OTR valves that withstand harsh conditions. Our TPMS system is also ideal for port cranes, providing a perfect tire pressure monitoring solution for your vehicles. Contact us for the options.
